RF-500TB Motor DC 6V 12V High Torque 2200RPM 3600RPM For Revolving Warning Lamp

The RF-500TB micro motor is primarily used in rotating warning lights to drive the rotation of the lamp cover, utilizing internal lighting to create a warning effect. The RF-500TB micro motor is a brushed DC motor with a model number of RF-500TB. It has a rated power range of 0.03W to 1.5W, a rated voltage range of 3V to 24V, and a rated speed range of 1200 to 9800 revolutions per minute (rpm).

Technical Specifications

• Motor Type:RF-500TB
• Operating Voltage: 6V–24V DC
• Rated Volt:6V 12V 24V
• Speed: 2200rpm(6V) 2600rpm(12V) 3600rpm(At 24V)Motor Diameter: 32mm
• Shaft Diameter: 2mm
• Shaft Length:8mm 10mm 20mm (customizable)
• Current (No Load): 12mA @ 6V, 10mA @ 12V 5mA @ 24V
• Torque: 50mN·m (adjustable up to 120g.cm)
• Weight: 50g
• Typical Motor Model:
  RF-500TB-09700: 6VDC No-load Speed:2200rpm No-load Current≤12mA
  RF-500TB-071250: 12VDC No-load Speed:2200rpm No-laod Current≤8mA
  RF-500TB-052600: 24VDC No-load Speed:2200rpm No-laod Current≤5mA
  RF-500TB-081200 : 12VDC No-load Speed:2600rpm No-laod Current≤10mA
  RF-500TB-062200 : 24VDC No-load Speed:2600rpm No-laod Current≤5mA
  RF-500TB-062200 : 24VDC No-load Speed:3600rpm No-laod Current≤7mA
  RF-500TB-071750A : 24VDC No-load Speed:3600±5%rpm No-laod Current≤10mA

RF-500TB Motor DC 6V 12V High Torque Motor Dimension

Notes:
1.Motor Body Length:17.5mm (Without Shaft length,terminal length)
2.Motor Output Shaft Length:L±0.5mm (Can be customized)
3.Motor Output Shaft Diameter:2mm
4.Motor Diameter:32mm
5.Fixed Aperture:M2.5*0.45mm
6.Step Height: about 1.8mm
7.Step diameter: about 6.2mm
8.Distance between two fixed aperture:22±0.1mm

9. Usable machine screw length 1. 0max. from motor mount ing surface.
AIlowable torque for screwing of tapped hole:2.5kgf-cm max.
No remarkab le scraches on dents on the sur face.
Tolerances not otherwise specified decimal: 士0.3mm.

Why Choose the RF-500 Motor From Lihua Motor?

✅ Premium Quality Assurance
Built with precision-engineered components and certified to ISO9001, REACH, SGS, and RoHS standards.
Achieving a 99.9% quality pass rate—ensuring consistent, reliable performance for your end products.

✅ Flexible Customization Solutions
Tailor motor specifications to your application needs—shaft lengths (5mm–20mm), gear ratios, and more.
OEM/ODM support for RF-500 motor solutions designed to meet your exact technical and operational requirements.

✅ Scalable Production with Fast Lead Times
Efficient production capacity with 15,000+ units daily.
30–40 days lead time for bulk orders and a 99% on-time delivery rate—helping you meet tight project schedules.

✅ Sustainable Manufacturing Practices
Environmentally responsible production using energy-efficient processes and recyclable materials.
Fully aligned with global sustainability standards—supporting your ESG commitments.

Description and Internal Factory Process for Customizing RF-500TB Motors

Requirement Confirmation

Customers provide detailed customization requirements, including electrical parameters, mechanical parameters, performance requirements, and environmental adaptability.

The sales and technical teams communicate with the customer to confirm details and provide a preliminary solution.

Design and Development

Engineers design the motor based on customer requirements, including structural design, material selection, and performance simulation.

Generate 2D engineering drawings and 3D models for customer confirmation.

Sample Production and Testing

The factory produces samples and conducts rigorous testing, including performance tests, durability tests, and environmental adaptability tests.

Provide test results to the customer for confirmation of whether the samples meet requirements.

Mass Production

After sample confirmation, the factory initiates mass production, ensuring each motor meets customer requirements and quality standards.

Conduct multiple quality inspections during production to ensure product consistency.

Packaging and Delivery

Package the products according to customer requirements (e.g., shockproof, moisture-proof, custom labeling).

Arrange logistics to ensure timely delivery.

After-Sales Service

Provide technical support and after-sales service to address any issues customers may encounter during use.

Regularly follow up on customer feedback to continuously improve products and services.
